100*100*100mm perforated coal honeycomb charcoal

The 100*100*100mm perforated coal honeycomb charcoal is manufactured from powdered activated carbon and binding agents and is suitable for this application.

1.Production Process: Base carbon pulverization, mixing, extrusion molding, drying, calcination or activation, cutting, dedusting, and quality inspection.

2.Product Features: Open-channel structure with low pressure drop, modular loading, and suitability for high-airflow systems.

3.Product Functions: Used for VOCs and odor control in high-airflow exhaust systems in painting, printing, electronics, and chemical processing facilities.

4.Main Series: Coal-Based Honeycomb Activated Carbon, available in 100-cell, 625-cell, 1600-cell, and other configurations, with standard and water-resistant versions. The iodine value or benzene adsorption performance is determined according to the specific exhaust gas composition. Suitable for VOCs and odor control in high-airflow exhaust systems in painting, printing, electronics, and chemical processing facilities.

5.Product Dimensions: The standard size is 100×100×100 mm.  Custom dimensions are also available upon request.

6.Customization Services: Dimensions, cell count, water resistance, compressive strength, iodine value, and benzene adsorption performance can be customized according to customer requirements.

7.Management Certifications: ISO 9001, ISO 14001, and ISO 45001.

8.Drinking Water Qualification: Coal-based granular activated carbon for water purification has obtained a drinking water hygiene and safety permit from Shanxi Province, China.

9.Technical Patents: Activated Carbon Purification Equipment for Water Treatment; Patent No.: ZL 2023 2 1056124.2.

10.Scientific & Technical Awards: Team members have received the Grand Prize for Scientific and Technological Progress under the Ministry of Education's Outstanding Scientific Research Achievement Awards for Higher Education Institutions, as well as the Second Prize for Scientific and Technological Progress from China North Industries Group Corporation (NORINCO Group).

11.Third-Party Audit: Supplier audit conducted by Bureau Veritas.

12.Sample Service: Free samples are available upon request.

13.Product Packaging: Packed in cartons. For the 100×100×100 mm specification, each carton contains 18 pieces. A total of 56 cartons make up 1 cubic meter, containing 1,008 pieces.

Coal-based honeycomb activated carbon is characterized by a large specific surface area, low resistance to airflow, a well-developed microporous structure, high adsorption capacity, and a long service life; it is widely used in air pollution control. The honeycomb activated carbon adsorption method involves bringing waste gas into contact with porous activated carbon—which possesses a large surface area—thereby adsorbing pollutants from the gas and achieving purification. At an airflow velocity of 2 meters per second, the flow resistance is less than 80 Pascals.

Clients may provide a test report for heavy metal content, or send us samples for analysis.

100*100*100mm Perforated Coal Honeycomb Charcoal – Industrial-Grade VOCs Adsorption Solution

When your facility faces VOCs compliance challenges, you need a solution that works immediately. Our 100*100*100mm perforated coal honeycomb charcoal delivers enterprise-level performance with a surface area exceeding 1100m²/g and VOCs removal efficiency above 90%. Made from high-quality anthracite coal and handled through high-temperature actuation, this standard-size honeycomb charcoal fits specifically into your 2×2×2m adsorption towers without modification—saving you over 50,000 RMB in tower overhaul costs. With weight drop underneath 450Pa and conveyance inside 5–7 working days, you get both vitality productivity and operational reliability.

Why Choose Coal-Based Honeycomb Charcoal for Your VOCs Treatment?

You're overseeing discuss volumes between 10,000 and 15,000 m³/h. You require steady results.

Our coal honeycomb charcoal structure gives the idealize adjust. The punctured plan permits tall wind current with negligible resistance. This implies your blowers work less. Your vitality bills drop. Your treatment effectiveness remains high.

The mystery lies in the fabricating handle. We begin with premium anthracite coal powder. Through specialized molding methods and high-temperature reactivation, we make a permeable structure. This gives you uncommon adsorption capacity without relinquishing mechanical strength.

Think of it as a infinitesimal labyrinth. Poisons enter through huge channels. They get caught in millions of minor pores. Clean discuss exits. It's that straightforward.

Technical Specifications You Can Trust

These aren't just numbers on paper. They represent 60+ years of activated carbon research and 20+ years of industrial production experience. Our quality management follows ISO 9001, ISO 14001, and ISO 45001 standards.

Common Technical Specifications

1. Iodine Value: Iodine value refers to the amount of iodine adsorbed by 1 gram of activated carbon from a 0.1 mol/L iodine solution, expressed in milligrams per gram (mg/g). It is commonly used as an important indicator of the adsorption capacity of activated carbon.

2. Specific Surface Area: Specific surface area refers to the total surface area of all particles contained in a unit mass of material.

3. Carbon Tetrachloride Adsorption Value (CTC): CTC is commonly used as an indicator of the adsorption capacity of activated carbon for organic gas molecules.

4. Benzene Adsorption Rate: Benzene adsorption rate is commonly used to evaluate the adsorption capacity of activated carbon for small organic molecules.

Technical Specification Table

Note: Our company can develop and manufacture water-resistant honeycomb activated carbon according to customer requirements.

Key Benefits That Impact Your Bottom Line

Perfect Fit, Zero Hassle

Your adsorption tower is 2×2×2 meters. Our 100*100*100mm perforated coal honeycomb charcoal stacks perfectly. No gaps. No custom cutting. No engineering headaches.

Significant Cost Savings

Skip the tower modification. That alone saves you more than 50,000 RMB per project. Lower pressure drop means your fans consume less electricity month after month.

Quick Replacement

When saturation happens, you can't afford long downtime. Standard sizing means your team replaces the charcoal in under 2 hours. Your production line keeps moving.

Consistent Performance

High mechanical strength means the charcoal maintains its structure under airflow pressure. You get stable adsorption throughout its service life.

Reliable Supply

We maintain stock across multiple production bases. When you order, we ship within 5–7 working days. Rush orders? We can deliver in as fast as 3 days.

Where This Honeycomb Charcoal Works Best

You'll find this coal-based honeycomb charcoal solving problems across industries:

• Chemical plants: Removing organic solvents from process exhaust
• Printing facilities: Controlling ink and solvent vapors
• Plastic manufacturing: Treating styrene and other polymer off-gases
• Coating operations: Capturing paint booth emissions
• Waste incineration: Reducing dioxin release
• Power generation: Assisting in flue gas desulfurization





The 100*100*100mm perforated coal honeycomb charcoal handles large volumes with low concentration organics efficiently. That's its sweet spot.

Frequently Asked Questions

What exactly is coal-based honeycomb activated charcoal?

It's a specialized form of activated carbon made from anthracite coal. We grind the coal into powder, mix it with binders, mold it into honeycomb structures with uniform channels, then activate it at high temperatures. The result is a material with massive internal surface area in a mechanically strong form.

Why choose the 100×100×100mm size specifically?

This is the industry standard size for 2×2×2 meter adsorption towers. It allows optimal packing density and airflow distribution. You avoid custom fabrication and fitting issues.

How does pressure drop affect my operation?

Lower pressure drop means your exhaust fans work less hard. Our product maintains pressure drop below 450Pa. This translates to measurable energy savings compared to denser materials.

Can this handle high humidity environments?

coal-based activated carbon performs well under normal industrial humidity. For extremely wet conditions, we can discuss customized solutions with hydrophobic treatments. Contact our technical team for specific applications.

How long does the charcoal last before replacement?

Service life depends on pollutant concentration and airflow. Typically, you'll see 6–18 months in standard VOCs applications. We recommend monitoring pressure drop increases and outlet concentrations to determine optimal replacement timing.

Do you offer customization?

Yes. While the 100×100×100mm size is standard, we can adjust iodine numbers, CTC values, and pore structures based on your specific pollutants. Our R&D team works with Tsinghua University and the Chinese Academy of Sciences to develop customized solutions.

What about international shipping?

We export globally via sea, air, and rail. Our Class A Customs Certification ensures faster clearance. We handle protective packaging, moisture barriers, and full documentation. Domestic delivery takes 3–7 days; international timing varies by destination.

How do I know if this product fits my application?

Share your air volume, pollutant types, concentrations, and tower specifications with us. Our engineers will assess compatibility and recommend the best configuration. This pre-sales consultation is complimentary.

Get Your VOCs Solution Today

Ready to improve your air treatment efficiency? Our team responds within 24 hours. Email us at greta@carbonxinhua.com with your 100*100*100mm perforated coal honeycomb charcoal project details.
